--- title: Overview of Single-Point Diamond Turned Optics - AOS description: Learn more about Single-Point Diamond Turned Optics and how Apollo Optical Systems is your go-to source for custom projects. image: https://21808144.fs1.hubspotusercontent-na1.net/hubfs/21808144/Imported_Blog_Media/Overview-of-Single-Point-Diamond-Turned-Optics.png --- [Skip to content](http://www.apollooptical.com/blog/overview-of-single-point-diamond-turned-optics#main-content) Close - [Markets](http://www.apollooptical.com/markets) - [Automotive](http://www.apollooptical.com/automotive-vertical) - [DMS & OMS](http://www.apollooptical.com/driver-monitoring-occupant-monitoring-system) - [Optical DFM Checklist](http://www.apollooptical.com/automotive-optical-dfm-checklist) - [DMS & OMS Polymer Optical Systems Solutions Guide](http://www.apollooptical.com/automotive-dms-oms-polymer-optical-systems-solutions-guide) - [Medical Devices](http://www.apollooptical.com/medical-devices) - [Tactical-Defense](http://www.apollooptical.com/tactical) - [Robotics](http://www.apollooptical.com/robotics-polymer-optics) - [Capabilities](http://www.apollooptical.com/capabilities-apollo-optical) - [Assembly](http://www.apollooptical.com/assembly) - [Coating as a Service](http://www.apollooptical.com/optical-coating-service) - [Diffractive Optics](http://www.apollooptical.com/diffractive-optics) - [Evaporative Coatings](http://www.apollooptical.com/evaporative-coatings) - [Metrology & Testing](http://www.apollooptical.com/metrology-testing) - [Microlens Arrays](http://www.apollooptical.com/microlens-arrays) - [Optical and Mechanical Design](http://www.apollooptical.com/optical-mechanical-design) - [Polymer Injection Molding](http://www.apollooptical.com/polymer-injection-molding) - [Polymer Raw Materials](http://www.apollooptical.com/polymer-raw-materials) - [Single Point Diamond Turning](http://www.apollooptical.com/single-point-diamond-turning) - [Company](http://www.apollooptical.com/about-apollo-optical) - [About Us](http://www.apollooptical.com/about-apollo-optical) - [Apollo Team](http://www.apollooptical.com/apollo-team) - [Careers](http://www.apollooptical.com/careers) - [FAQ](http://www.apollooptical.com/optical-manufacturing-faq) - Learn - [Resources](http://www.apollooptical.com/resources-references-polymer-optics) - [Common Polymers for Optical Components](http://www.apollooptical.com/common-polymers-for-optical-components) - [Material Transmission Data and Graphs](http://www.apollooptical.com/material-transmission-data-graphs) - [Manufacturing Tolerances](http://www.apollooptical.com/manufacturing-tolerances) - [Glossary](http://www.apollooptical.com/glossary-polymer-optics-terminology) - [Polymer Catalog for Zemax](http://www.apollooptical.com/polymer-catalog-zemax) - [Resources for the Optics Curious](https://www.apollooptical.com/blog/tag/burallis-bytes) - [Apollo Optical Insights](http://www.apollooptical.com/blog) SEARCH [Contact Us](http://www.apollooptical.com/contact-apollo-optical) [![Apollo Optical-LOGO-FF-01-1](https://21808144.fs1.hubspotusercontent-na1.net/hub/21808144/hubfs/Apollo%20Optical-LOGO-FF-01-1.png?width=2134&height=812&name=Apollo%20Optical-LOGO-FF-01-1.png)](http://www.apollooptical.com)[![Apollo Optical-LOGO-WHITE-FF-01-1](https://21808144.fs1.hubspotusercontent-na1.net/hub/21808144/hubfs/Apollo%20Optical-LOGO-WHITE-FF-01-1.png?width=2214&height=2665&name=Apollo%20Optical-LOGO-WHITE-FF-01-1.png)](http://www.apollooptical.com) - [Markets](http://www.apollooptical.com/markets) - [Automotive](http://www.apollooptical.com/automotive-vertical) - [DMS & OMS](http://www.apollooptical.com/driver-monitoring-occupant-monitoring-system) - [Optical DFM Checklist](http://www.apollooptical.com/automotive-optical-dfm-checklist) - [DMS & OMS Polymer Optical Systems Solutions Guide](http://www.apollooptical.com/automotive-dms-oms-polymer-optical-systems-solutions-guide) - [Medical Devices](http://www.apollooptical.com/medical-devices) - [Tactical-Defense](http://www.apollooptical.com/tactical) - [Robotics](http://www.apollooptical.com/robotics-polymer-optics) - [Capabilities](http://www.apollooptical.com/capabilities-apollo-optical) - [Assembly](http://www.apollooptical.com/assembly) - [Coating as a Service](http://www.apollooptical.com/optical-coating-service) - [Diffractive Optics](http://www.apollooptical.com/diffractive-optics) - [Evaporative Coatings](http://www.apollooptical.com/evaporative-coatings) - [Metrology & Testing](http://www.apollooptical.com/metrology-testing) - [Microlens Arrays](http://www.apollooptical.com/microlens-arrays) - [Optical and Mechanical Design](http://www.apollooptical.com/optical-mechanical-design) - [Polymer Injection Molding](http://www.apollooptical.com/polymer-injection-molding) - [Polymer Raw Materials](http://www.apollooptical.com/polymer-raw-materials) - [Single Point Diamond Turning](http://www.apollooptical.com/single-point-diamond-turning) - [Company](http://www.apollooptical.com/about-apollo-optical) - [About Us](http://www.apollooptical.com/about-apollo-optical) - [Apollo Team](http://www.apollooptical.com/apollo-team) - [Careers](http://www.apollooptical.com/careers) - [FAQ](http://www.apollooptical.com/optical-manufacturing-faq) - Learn - [Resources](http://www.apollooptical.com/resources-references-polymer-optics) - [Common Polymers for Optical Components](http://www.apollooptical.com/common-polymers-for-optical-components) - [Material Transmission Data and Graphs](http://www.apollooptical.com/material-transmission-data-graphs) - [Manufacturing Tolerances](http://www.apollooptical.com/manufacturing-tolerances) - [Glossary](http://www.apollooptical.com/glossary-polymer-optics-terminology) - [Polymer Catalog for Zemax](http://www.apollooptical.com/polymer-catalog-zemax) - [Resources for the Optics Curious](https://www.apollooptical.com/blog/tag/burallis-bytes) - [Apollo Optical Insights](http://www.apollooptical.com/blog) [Contact Us](http://www.apollooptical.com/contact-apollo-optical) Quick results for "{search\_term}" ![](https://21808144.fs1.hubspotusercontent-na1.net/hub/21808144/hubfs/Imported_Blog_Media/Overview-of-Single-Point-Diamond-Turned-Optics.png?width=300&name=Overview-of-Single-Point-Diamond-Turned-Optics.png) [Apollo Optical Systems](http://www.apollooptical.com/blog/author/apollo-optical-systems)January 30, 20234 min read # Overview of Single-Point Diamond Turned Optics [Previous](http://www.apollooptical.com/blog/visit-aos-at-spie-photonics-west-2023) [Next](http://www.apollooptical.com/blog/why-is-injection-molding-the-ideal-technique-for-mass-production) Single-point diamond turning is a process of mechanical machining of precision elements equipped with diamond-tipped tool bits. The process used for single-point diamond turned optics may be applied to the manufacturing of high-quality aspheric optical elements from acrylic, metals, crystals, and other materials. Optical elements created by single-point diamond turning are often used for optical assemblies in video projectors, missile guidance systems, telescopes, lasers, and other systems and devices. Most single-point diamond turning is done with the aid of computer numerical control (CNC) machine tools. ## **What Is Single-Point Diamond Turning?** Single-point diamond turning is a manufacturing process that’s used to produce low to moderate volumes of [accurate and precise optics](https://www.apollooptical.com/custom-versus-off-the-shelf-ots-optics/), typically for research and development or prototyping. This manufacturing method offers several key advantages over other methods. It offers speed of delivery, reduced tooling costs, high accuracy, and sophisticated surface profiles. As a result, the overall manufacturing lead times are much lower. Also, because of the high accuracy and precision of turning equipment, the surface finishes and errors in form that may be created in the process are tightly controlled and therefore minimized. Single-point diamond turning can also create complex surface geometries, such as off-axis aspheric and [freeform surfaces.](https://d.docs.live.net/freeform-optics-for-ar-vr-glasses-metasurfaces-metaforms) ## **Single-Point Diamond Turning Process** The machine used for diamond turning has several axes: \[1\] - X axis, which is the feeding direction - Y axis, which controls the height of the workpiece - Z axis, which is the infeed direction - C axis, which is the turning point A nozzle is placed next to the diamond tool. A cooling liquid is needed to cool the contact point when cutting metal. With plastic, air is used to avoid damaging the material. Before cutting, the workpiece must be placed at the center of the spindle to ensure that the rotation axis is the same as the spindle. A gauge is used to detect the centering, then a hammer is used to move the workpiece. There are 12 screws on the side of the spindle. Adjusting the position of the screws changes the spindle’s balance, ensuring it’s moving smoothly during the cutting process. The tool position must also be aligned before the cutting can begin. The Y axis is aligned using a microscope. If it’s misaligned, the center will leave materials behind. The X axis must be aligned using an interferometer to ensure the correct shape of the workpiece. Once the process is complete, and the surface has been fabricated, the workpiece is removed from the spindle to be measured. The surface is measured by both a standard interferometer to determine the surface shape and an interferometric microscope to test the roughness of the surface. The entire process must be repeated if the optical surface is inaccurate compared to the preferred shape or roughness. ## **Types of Surfaces** There are several types of surfaces used in single-point diamond turning: ### **Aspherical Surface:** These surfaces have at least one optical surface of non-constant radius of curvature. These parameters can be set, and the machine can generate the coordinates according to the radius of the diamond tool to allow an aspherical surface to be cut. This is one of the most common surface types for single-point diamond turning. ### [**Lens Array:**](https://www.apollooptical.com/microlens-arrays/) This can be fabricated after extensive design. Lens arrays are difficult to cut and may require special tools or a unique cutting procedure. ### **Freeform:** These optical shapes or surfaces are designed with little to no symmetry. Manufacturing freeform is similar to manufacturing a complex aspherical surface. ## **Single-Point Diamond Turned Optics at Apollo Optical Systems** Apollo Optical Systems is a leader in optical surface finishes and performance with both plastic and metals using [single-point diamond turning](https://www.apollooptical.com/single-point-diamond-turning/). The process can fabricate small quantities of custom optical prototypes before mass production. We currently have three single-point diamond turning lathes: Two Precitech Optimum 2400 two-axis lathes and one three-axis Precitech Nanoform 200 lathe. We also offer: - Custom proprietary diamond tools with radii as small as 1.5 micron - Optical components from 1 mm to 300 mm in diameter - Better than average finishes in any material - A 30-50 A RMS surface finish and \< ¼ wave peak-to-valley surface figure ### **Materials Used for Single-Point Diamond Turning** Apollo Optical Systems uses a wide variety of materials for single-point diamond turning, including: - Plastics - Acetal - Acrylic - Nylon - Polypropylene - Polystyrene - Zeonex - Zeonor - Metals - Aluminum and aluminum alloys - Brass - Copper - Gold - Nickel-phosphorus - Silver - Tin - Zinc ## **Contact Apollo Optical Systems** Apollo Optical Systems combines knowledge and experience with optical design and metrology to ensure a successful final optical element. [Contact us](https://www.apollooptical.com/contact-us/) today to discuss your custom optics project!   **Sources:** \[1\] [https://wp.optics.arizona.edu/optomech/wp-content/uploads/sites/53/2016/12/Tutorial\_ChengHN.pdf](https://wp.optics.arizona.edu/optomech/wp-content/uploads/sites/53/2016/12/Tutorial_ChengHN.pdf)   ![](https://21808144.fs1.hubspotusercontent-na1.net/hub/21808144/hubfs/Imported_Blog_Media/94fe56ba9e7dc405d60eb55a67091f2b-Mar-16-2024-12-13-40-6090-AM.jpeg?width=68&height=68&name=94fe56ba9e7dc405d60eb55a67091f2b-Mar-16-2024-12-13-40-6090-AM.jpeg) #### About Dale Buralli Dr. Dale Buralli has served as the Chief Scientist for Apollo Optical Systems since 2003. In this role, Dr. Buralli is responsible for the design and optical modeling of various optical systems. These systems include virtual or augmented reality, ophthalmic and other imaging or illumination systems. Additionally, he provides support for optical tooling of lens molds and prototypes, including the development of custom software for both production and metrology. Dr. Buralli got his Ph.D. in optics from the University of Rochester in 1991. Now he is an Adjunct Professor of Optics at the University of Rochester’s Institute of Optics. [View all posts by Dale Buralli →](https://www.apollooptical.com/author/dale-buralli/) #### [Apollo Optical Systems](http://www.apollooptical.com/blog/author/apollo-optical-systems) ## RELATED ARTICLES [![Apollo Optical-LOGO-WHITE v2-1](https://21808144.fs1.hubspotusercontent-na1.net/hub/21808144/hubfs/Apollo%20Optical-LOGO-WHITE%20v2-1.png?width=300&name=Apollo%20Optical-LOGO-WHITE%20v2-1.png)](http://apollooptical.com) © 2026 Apollo Optical Systems Inc. All rights reserved [925 John Street West Henrietta, NY 14586](https://maps.app.goo.gl/7SARBFb2gTeHAJgy6) ![ISO certified logo](https://21808144.fs1.hubspotusercontent-na1.net/hub/21808144/hubfs/iso-9001-certified-dark.png?width=75&height=75&name=iso-9001-certified-dark.png) - [Markets](http://www.apollooptical.com/capabilities-apollo-optical) - [Capabilities](http://www.apollooptical.com/capabilities-apollo-optical) - [Coating as a Service](http://www.apollooptical.com/optical-coating-service) - [Evaporative Coatings](http://www.apollooptical.com/evaporative-coatings) - [Metrology & Testing](http://www.apollooptical.com/metrology-testing) - [Microlens Arrays](http://www.apollooptical.com/microlens-arrays) - [Optical and Mechanical Design](http://www.apollooptical.com/optical-mechanical-design) - [Polymer Injection Molding](http://www.apollooptical.com/polymer-injection-molding) - [Single Point Diamond Turning (SPDT)](http://www.apollooptical.com/single-point-diamond-turning) - [Company](http://www.apollooptical.com/about-apollo-optical) - [Contact Us](http://www.apollooptical.com/contact-apollo-optical) - [Careers](http://www.apollooptical.com/careers) - [Apollo Optical Insights](http://www.apollooptical.com/blog) - [Resources](http://www.apollooptical.com/resources-references-polymer-optics) - [Markets](http://www.apollooptical.com/markets) - [Blog](https://www.apollooptical.com/feeds) - [Privacy Policy](http://www.apollooptical.com/privacy-policy) SUBSCRIBE TO OUR NEWSLETTER Stay up to date on the latest products, and services from Apollo Optical Systems! ```json { "@context" : "https://schema.org", "@type" : "Organization", "address" : { "@type" : "PostalAddress", "addressCountry" : "US", "addressLocality" : "West Henrietta", "addressRegion" : "NY", "postalCode" : "14586", "streetAddress" : "925 John St" }, "knowsLanguage" : "en", "logo" : { "@type" : "ImageObject", "url" : "https://21808144.fs1.hubspotusercontent-na1.net/hubfs/21808144/Apollo%20Optical-LOGO-FF-01-1.png" }, "name" : "Apollo Optical Systems", "url" : "http://www.apollooptical.com/blog/overview-of-single-point-diamond-turned-optics" } ``` ```json { "@context" : "https://schema.org", "@type" : "BlogPosting", "abstract" : "Learn more about Single-Point Diamond Turned Optics and how Apollo Optical Systems is your go-to source for custom projects.", "author" : { "@type" : "Person", "name" : "Apollo Optical Systems" }, "dateModified" : "August 3, 2026 12 PM", "datePublished" : "January 30, 2023 5 AM", "headline" : "Overview of Single-Point Diamond Turned Optics", "image" : "https://21808144.fs1.hubspotusercontent-na1.net/hubfs/21808144/Imported_Blog_Media/Overview-of-Single-Point-Diamond-Turned-Optics.png", "inLanguage" : "en", "keywords" : "[News & Personnel]", "mainEntityOfPage" : { "@type" : "WebPage" }, "name" : "Overview of Single-Point Diamond Turned Optics", "publisher" : { "@type" : "Organization", "logo" : { "@type" : "ImageObject", "url" : "https://21808144.fs1.hubspotusercontent-na1.net/hubfs/21808144/Apollo%20Optical-LOGO-FF-01-1.png" }, "name" : "Apollo Optical Systems" }, "text" : "Single-point diamond turning is a process of mechanical machining of precision elements equipped with diamond-tipped tool bits. The process used for single-point diamond turned optics may be applied to the manufacturing of high-quality aspheric optical elements from acrylic, metals, crystals, and other materials. Optical elements created by single-point diamond turning are often used for optical assemblies in video projectors, missile guidance systems, telescopes, lasers, and other systems and devices. Most single-point diamond turning is done with the aid of computer numerical control (CNC) machine tools. What Is Single-Point Diamond Turning? Single-point diamond turning is a manufacturing process that’s used to produce low to moderate volumes of accurate and precise optics, typically for research and development or prototyping. This manufacturing method offers several key advantages over other methods. It offers speed of delivery, reduced tooling costs, high accuracy, and sophisticated surface profiles. As a result, the overall manufacturing lead times are much lower. Also, because of the high accuracy and precision of turning equipment, the surface finishes and errors in form that may be created in the process are tightly controlled and therefore minimized. Single-point diamond turning can also create complex surface geometries, such as off-axis aspheric and freeform surfaces. Single-Point Diamond Turning Process The machine used for diamond turning has several axes: [1] X axis, which is the feeding direction Y axis, which controls the height of the workpiece Z axis, which is the infeed direction C axis, which is the turning point A nozzle is placed next to the diamond tool. A cooling liquid is needed to cool the contact point when cutting metal. With plastic, air is used to avoid damaging the material. Before cutting, the workpiece must be placed at the center of the spindle to ensure that the rotation axis is the same as the spindle. A gauge is used to detect the centering, then a hammer is used to move the workpiece. There are 12 screws on the side of the spindle. Adjusting the position of the screws changes the spindle’s balance, ensuring it’s moving smoothly during the cutting process. The tool position must also be aligned before the cutting can begin. The Y axis is aligned using a microscope. If it’s misaligned, the center will leave materials behind. The X axis must be aligned using an interferometer to ensure the correct shape of the workpiece. Once the process is complete, and the surface has been fabricated, the workpiece is removed from the spindle to be measured. The surface is measured by both a standard interferometer to determine the surface shape and an interferometric microscope to test the roughness of the surface. The entire process must be repeated if the optical surface is inaccurate compared to the preferred shape or roughness. Types of Surfaces There are several types of surfaces used in single-point diamond turning: Aspherical Surface: These surfaces have at least one optical surface of non-constant radius of curvature. These parameters can be set, and the machine can generate the coordinates according to the radius of the diamond tool to allow an aspherical surface to be cut. This is one of the most common surface types for single-point diamond turning. Lens Array: This can be fabricated after extensive design. Lens arrays are difficult to cut and may require special tools or a unique cutting procedure. Freeform: These optical shapes or surfaces are designed with little to no symmetry. Manufacturing freeform is similar to manufacturing a complex aspherical surface. Single-Point Diamond Turned Optics at Apollo Optical Systems Apollo Optical Systems is a leader in optical surface finishes and performance with both plastic and metals using single-point diamond turning. The process can fabricate small quantities of custom optical prototypes before mass production. We currently have three single-point diamond turning lathes: Two Precitech Optimum 2400 two-axis lathes and one three-axis Precitech Nanoform 200 lathe. We also offer: Custom proprietary diamond tools with radii as small as 1.5 micron Optical components from 1 mm to 300 mm in diameter Better than average finishes in any material A 30-50 A RMS surface finish and < ¼ wave peak-to-valley surface figure Materials Used for Single-Point Diamond Turning Apollo Optical Systems uses a wide variety of materials for single-point diamond turning, including: Plastics Acetal Acrylic Nylon Polypropylene Polystyrene Zeonex Zeonor Metals Aluminum and aluminum alloys Brass Copper Gold Nickel-phosphorus Silver Tin Zinc Contact Apollo Optical Systems Apollo Optical Systems combines knowledge and experience with optical design and metrology to ensure a successful final optical element. Contact us today to discuss your custom optics project! Sources: [1] https://wp.optics.arizona.edu/optomech/wp-content/uploads/sites/53/2016/12/Tutorial_ChengHN.pdf About Dale Buralli Dr. Dale Buralli has served as the Chief Scientist for Apollo Optical Systems since 2003. In this role, Dr. Buralli is responsible for the design and optical modeling of various optical systems. These systems include virtual or augmented reality, ophthalmic and other imaging or illumination systems. Additionally, he provides support for optical tooling of lens molds and prototypes, including the development of custom software for both production and metrology. Dr. Buralli got his Ph.D. in optics from the University of Rochester in 1991. Now he is an Adjunct Professor of Optics at the University of Rochester’s Institute of Optics. View all posts by Dale Buralli →", "url" : "http://www.apollooptical.com/blog/overview-of-single-point-diamond-turned-optics", "wordCount" : "1271" } ``` ```json { "@context" : "https://schema.org", "@type" : "BlogPosting", "author" : { "@type" : "Person", "name" : "Apollo Optical Systems", "url" : "http://www.apollooptical.com/blog/author/apollo-optical-systems" }, "dateModified" : "2024-03-16T00:14:14.920Z", "datePublished" : "2023-01-30T05:00:00.000Z", "headline" : "Overview of Single-Point Diamond Turned Optics - AOS", "image" : [ "https://21808144.fs1.hubspotusercontent-na1.net/hubfs/21808144/Imported_Blog_Media/Overview-of-Single-Point-Diamond-Turned-Optics.png" ], "mainEntityOfPage" : { "@id" : "http://www.apollooptical.com/blog/overview-of-single-point-diamond-turned-optics", "@type" : "WebPage" }, "publisher" : { "@type" : "Organization", "logo" : { "@type" : "ImageObject", "url" : "https://21808144.fs1.hubspotusercontent-na1.net/hubfs/21808144/Apollo%20Optical-LOGO-FF-01-1.png" }, "name" : "Apollo Optical Systems" } } ```
